Linear rail of X/Y/Z axis, composite and integrated machining center
Advantages of the product
The product has the machining range which is much greater than that of common 1m machine, and the rigidity is increased greatly at the same time. The high-power motor up to 15KW is taken as the spindle motor; with the adoption of the super-wide machine tool base, columns, 45mm three-axis heavy-duty roller type guide rails, and six sliding blocks on the Axis X and Axis Z, the rigidity requirements of the bearing axis is strengthened, and the machine tool can more effectively absorb vibration during heavy cut; and accordingly the accuracy and degree of finish of the workpiece are improved. Therefore, 1160 type machine is the perfect combination of high speed and high rigidity.
Structure introduction of the machine tool body
On the basis of common 1060 type machine, strengthened machining is implemented on a saddle of the table; 45mm heavy duty guide rails are applied to the guide rails of three axes; the table is not suspended in midair during displacement due to the super-wide span between the guide rails; and 6 sliding blocks are used on the Axis X and Axis Z, thereby greatly strengthening the bearing rigidity. This type of machine tool has big stroke and high rigidity, and can totally meet machining requirements of the most of the steel parts.
Technical Parameters
| Basic specification: | unit | GV-1160 |
| Stroke | ||
| Strokes of Axes X, Y and Z | mm | 1100×600×600 |
| Nose of the Spindle to the Table Surface | mm | 140-740 |
| Center of the Spindle to the Shield Surface of Axis Z | mm | 630 |
| Maximum Load of the Table | ||
| Table Size | mm | 1200×600 |
| Maximum Load of the Table | kg | 1000 |
| Size of T-Shaped Slot (Width * Number of Slots * Interval) | mm | 18×5×100 |
| Spindle | ||
| Revolving Speed of Spindle | rpm | 8000 |
| Horsepower of Spindle Motor | kw | 15 |
| Taper of Spindle | BT-40（OptionalBT-50） | |
| Diameter of Spindle | mm | 150/155 |
| Feed Rate | ||
| Maximum feed rates of Axes X, Y and Z | m/min | 36×36×36 |
| Accuracy | ||
| Repeated Accuracy | mm | ±0.003 |
| Positioning Accuracy | mm | ±0.005 |
| Automatic tool changer | ||
| Form of Tool Changer | Knife arm | |
| Capacity of the Tool Magazine | support | 24 |
| Maximum Tool Diameter | mm | 80/150 |
| Maximum Tool Length | mm | 300 |
| Maximum Tool Weight | kg | 8 |
| Tool changing time (T-T) | sec | 1.8 |
| Power Source | ||
| Pressure of air machine | kgf/cm2 | 7 |
| Power demand | KVA | 25 |
| Size and weight of the machine | ||
| Net weight | T | 7 |
| Overall size (length * width*height) | m | 3.1×2.4×2.7 |
